Wili Heat Trace Control Panels – WiCtrl™
Intelligent Temperature Control Solutions for Industrial Heat Tracing Systems
At Wili Co., Ltd., we provide a comprehensive range of Heat Trace Control Panels engineered to deliver precise temperature control, reliable system protection, and intelligent monitoring for electric heat tracing applications. Designed for industrial environments, our control panels integrate advanced control technologies with high-quality electrical components to ensure safe, energy-efficient, and dependable operation.
Whether protecting pipelines from freezing or maintaining critical process temperatures, Wili control panels are customized to meet the specific requirements of each project, from small utility systems to large-scale industrial facilities.
Complete Heat Trace Control Solutions
Our control panels are available in a wide range of configurations to suit different applications and project specifications.
Single Circuit Control Panels
Designed for individual heat tracing circuits, these compact panels provide:
- Accurate electronic temperature control
- Freeze protection
- Process temperature maintenance
- RTD temperature sensing
- Alarm indication
- Ground fault protection
- Circuit breaker protection
Ideal for:
- Small pipelines
- Valves
- Instrument tubing
- Process equipment
- Storage vessels
Multi-Circuit Control Panels
For larger installations, Wili offers multi-circuit control panels capable of managing multiple heating circuits from one centralized enclosure.
Features include:
- Individual circuit control
- Independent temperature monitoring
- Current monitoring
- Ground leakage detection
- Alarm management
- Data logging
- Modular expansion
Suitable for:
- Refineries
- Petrochemical plants
- LNG terminals
- Chemical processing facilities
- Tank farms
- Offshore platforms
Intelligent Temperature Control
Our control systems support multiple control methods, including:
- On/Off Temperature Control
- Ambient Sensing Control
- Proportional Control
- High Temperature Limiting
- Freeze Protection Control
- Process Temperature Maintenance
Advanced algorithms optimize heater operation, reducing energy consumption while maintaining precise process temperatures.
Comprehensive Monitoring
Wili heat trace control panels continuously monitor critical operating parameters, including:
- Process temperature
- Ambient temperature
- Heater current
- Ground fault current
- Power status
- RTD sensor condition
- Circuit health
- Alarm status
- Communication status
Real-time monitoring enables early detection of abnormal conditions, reducing maintenance costs and preventing unexpected downtime.
Smart Alarm Management
Our panels provide intelligent alarm functions such as:
- High Temperature Alarm
- Low Temperature Alarm
- High Current Alarm
- Ground Fault Alarm
- Sensor Failure Alarm
- Power Failure Alarm
- Communication Failure Alarm
- Circuit Breaker Trip Alarm
Visual indicators and configurable alarm outputs ensure operators are immediately informed of system events.
Industrial Communication
Wili control panels can be integrated with modern industrial automation systems through various communication protocols, including:
- Modbus RTU
- Modbus TCP/IP
- Ethernet
- RS485
- SCADA Integration
- Distributed Control System (DCS) Integration
- Building Management System (BMS) Integration
This allows centralized monitoring and control of heat tracing assets across an entire facility.
Premium Electrical Components
To ensure long-term reliability, Wili utilizes high-quality components from globally recognized manufacturers, including:
- Thermon
- Schneider Electric
- Siemens
- ABB
- Phoenix Contact
- Weidmüller
- Omron
- Eaton
- Rittal
- Mean Well
Equivalent components can also be supplied according to customer preferences or project specifications.
Custom Engineering
Every industrial facility has unique operating conditions. Wili designs custom control panels tailored to specific project requirements, including:
- Voltage and frequency
- Number of heating circuits
- Hazardous or non-hazardous installation
- Environmental protection rating (IP / NEMA)
- Controller selection
- Communication requirements
- Panel dimensions
- Local and international standards
Panels are available in carbon steel, stainless steel (304/316), or GRP enclosures depending on the application.
Order Code
A:WiCtrl : Panel type
B:230V/380V/400V/600V
C: Total Ampere : Total A
D: Control type : ON-OFF=O/PID=P/PLC =L
E: Input : PT100:PT/4-20mA=A
F: Output : Relay=R; SSR=S;SCR=C
G: number of Zone : 1,2,3….N
H: Each Zone power : 10A;16A; 25A;32A;40A;50A…
I: Panel material : Galvanized painted steel : ST ; Stainless steel :SS304; SS316
For example: WiCtrl-230-150A-P-PT-S-16-25A-SS304
Typical Applications
Wili heat trace control panels are widely used in:
- Oil & Gas
- Petrochemical
- Chemical Processing
- LNG Facilities
- Power Generation
- Water & Wastewater Treatment
- Food & Beverage
- Pharmaceutical Manufacturing
- Mining
- Marine & Offshore
- Tank Farms
- Commercial Buildings
- Fire Protection Systems
Advantages of Wili Heat Trace Control Panels
- Customized engineering solutions
- Reliable and precise temperature control
- High-quality international components
- Modular and scalable design
- Energy-efficient operation
- User-friendly interface
- Easy installation and maintenance
- Advanced alarm and monitoring functions
- Integration with plant automation systems
- Compliance with international standards
- Long service life with low maintenance requirements
Our Heat Trace Control Portfolio
Wili can supply and integrate a wide range of advanced Thermon control technologies, including:
- Genesis Controller™ – Multi-circuit industrial control system
- Genesis Duo™ – Dual-circuit intelligent controller
- Genesis Evo™ – Retrofit solution for existing control panels
- Genesis Network™ – IIoT communication and monitoring platform
- Egis™ Platform – Centralized asset management software
- TraceNet™ ECM – Field-mounted electronic control module
- TraceNet™ TCM2 – Dual-circuit electronic controller
- EXO TOUCH™ – Commercial touchscreen heat trace controller
By combining these technologies with Wili’s engineering expertise, we deliver complete, integrated heat trace control solutions tailored to each customer’s operational needs.
Why Choose Wili?
With years of experience in industrial thermal management, Wili provides more than just electrical control panels—we deliver complete heat tracing solutions that combine engineering excellence, reliable products, and responsive technical support.
Our experienced engineering team works closely with clients from project design through commissioning and after-sales service, ensuring every system achieves optimal safety, efficiency, and long-term performance.
Whether you require a simple single-circuit panel or a plant-wide heat trace monitoring system, Wili is your trusted partner for intelligent heat trace control solutions.
